Systemd kasutamine

# ls -ld /sbin/init
lrwxrwxrwx 1 root root 20 Sep 28 22:33 /sbin/init -> /lib/systemd/systemd

# apt-get install dbus libpolkit-agent-1-0

# systemctl status ssh.service
● ssh.service - OpenBSD Secure Shell server
   Loaded: loaded (/lib/systemd/system/ssh.service; enabled)
   Active: active (running) since Tue 2014-11-04 02:43:10 EET; 18h ago
 Main PID: 1956 (sshd)
   CGroup: /system.slice/ssh.service
           └─1956 /usr/sbin/sshd -D

# cat /lib/systemd/system/ssh.service
[Unit]
Description=OpenBSD Secure Shell server
After=network.target auditd.service
ConditionPathExists=!/etc/ssh/sshd_not_to_be_run

[Service]
EnvironmentFile=-/etc/default/ssh
ExecStart=/usr/sbin/sshd -D $SSHD_OPTS
ExecReload=/bin/kill -HUP $MAINPID
KillMode=process
Restart=on-failure

[Install]
WantedBy=multi-user.target
Alias=sshd.service

# systemctl  list-units --type=service | head -n 5
  UNIT                                 LOAD   ACTIVE SUB     DESCRIPTION
  accounts-daemon.service              loaded active running Accounts Service
  acpid.service                        loaded active exited  LSB: Start the Advanced Configuration and Power Interface daemon
  amavis-mc.service                    loaded active exited  LSB: Startup script for amavis master supervisor
  amavis.service                       loaded active running LSB: Starts amavisd-new mailfilter

# systemctl list-units --type=service --state=exited
UNIT                             LOAD   ACTIVE SUB    DESCRIPTION
getty-static.service             loaded active exited getty on tty2-tty6 if dbus and logind are not available
kbd.service                      loaded active exited LSB: Prepare console
keymap.service                   loaded active exited LSB: Set keymap
modules_dep.service              loaded active exited LSB: modules.dep creation.
netfilter-persistent.service     loaded active exited netfilter persistent configuration
networking.service               loaded active exited LSB: Raise network interfaces.
quota.service                    loaded active exited Check And Enable File System Quotas
rc-local.service                 loaded active exited /etc/rc.local Compatibility
systemd-random-seed.service      loaded active exited Load/Save Random Seed

# timedatectl list-timezones
# timedatectl set-timezone Europe/Tallinn

# timedatectl set-ntp true

# systemctl enable systemd-timesyncd
# systemctl start systemd-timesyncd

# timedatectl status
      Local time: Fri 2015-07-31 01:21:26 EEST
  Universal time: Thu 2015-07-30 22:21:26 UTC
        RTC time: Thu 2015-07-30 22:21:26
       Time zone: Europe/Tallinn (EEST, +0300)
     NTP enabled: yes
NTP synchronized: no
 RTC in local TZ: no
      DST active: yes
 Last DST change: DST began at
                  Sun 2015-03-29 02:59:59 EET
                  Sun 2015-03-29 04:00:00 EEST
 Next DST change: DST ends (the clock jumps one hour backwards) at
                  Sun 2015-10-25 03:59:59 EEST
                  Sun 2015-10-25 03:00:00 EET

# cat /etc/systemd/timesyncd.conf
[Time]
Servers=10.192.0.53

# systemctl restart systemd-timesyncd

# systemctl status systemd-timesyncd
● systemd-timesyncd.service - Network Time Synchronization
   Loaded: loaded (/lib/systemd/system/systemd-timesyncd.service; enabled)
   Active: active (running) since Fri 2015-07-31 09:13:18 EEST; 1min 43s ago
     Docs: man:systemd-timesyncd.service(8)
 Main PID: 1179 (systemd-timesyn)
   Status: "Using Time Server 10.192.0.53:123 (10.192.0.53)."
   CGroup: /system.slice/systemd-timesyncd.service
           └─1179 /lib/systemd/systemd-timesyncd

Jul 31 09:13:17 postkast systemd-timesyncd[1179]: Using NTP server 10.192.0.53:123 (10.192.0.53).
Jul 31 09:13:18 postkast systemd-timesyncd[1179]: interval/delta/delay/jitter/drift 32s/+0.621s/0.000s/0.000s/+0ppm
Jul 31 09:13:50 postkast systemd-timesyncd[1179]: interval/delta/delay/jitter/drift 64s/+0.000s/0.000s/0.000s/+0ppm
Jul 31 09:14:54 postkast systemd-timesyncd[1179]: interval/delta/delay/jitter/drift 128s/-0.000s/0.000s/0.000s/+0ppm

# systemctl status systemd-timedated
● systemd-timedated.service - Time & Date Service
   Loaded: loaded (/lib/systemd/system/systemd-timedated.service; static)
   Active: inactive (dead)
     Docs: man:systemd-timedated.service(8)
           man:localtime(5)
           http://www.freedesktop.org/wiki/Software/systemd/timedated

# pg_createcluster 9.4 test

# systemctl start postgresql@9.4-test

# ps -U postgres -o pid,user,cgroup:150,args
  PID USER     CGROUP                                                                           COMMAND
10064 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service /usr/lib/postgresql/9.4/bin/postgres -D /va ...
10070 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service postgres: checkpointer process
10072 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service postgres: writer process
10074 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service postgres: wal writer process
10076 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service postgres: autovacuum launcher process
10078 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-main.service postgres: stats collector process

10331 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service /usr/lib/postgresql/9.4/bin/postgres -D /var ...
10333 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service postgres: checkpointer process
10334 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service postgres: writer process
10335 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service postgres: wal writer process
10336 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service postgres: autovacuum launcher process
10337 postgres 8:devices:/system.slice/system-postgresql.slice ... /postgresql@9.4-test.service postgres: stats collector process

# systemctl kill -s SIGKILL postgresql@9.4-test.service

# systemctl stop smbd
# systemctl stop nmbd

# ps aux | grep mb

# systemctl start samba-ad-dc

# systemctl start openvpn@client.service

# systemctl enable serial-getty@ttyS0.service
Created symlink from /etc/systemd/system/getty.target.wants/serial-getty@ttyS0.service \
  to /lib/systemd/system/serial-getty@.service.

# systemctl start serial-getty@ttyS0.service

# systemctl status nut-server
# systemctl status nut-client

# systemctl stop syslog.socket rsyslog.service

# grep ^ExecS /lib/systemd/system/varnish.service
ExecStart=/usr/sbin/varnishd -j unix,user=vcache -F -a :80 -T localhost:6082 -f /etc/varnish/default.vcl -S /etc/varnish/secret -s malloc,256m

# grep ^ExecS /lib/systemd/system/varnishncsa.service
ExecStart=/usr/bin/varnishncsa -F '%%{X-Forwarded-For}i %%l %%u %%t \"%%r\" %%s %%b \"%%{Referer}i\" \"%%{User-agent}i\"' -a -w /var/log/varnish/varnishncsa.log

# systemctl daemon-reload
# /etc/init.d/varnishncsa restart
# /etc/init.d/varnish restart

# tail -f /var/log/varnish/varnishncsa.log
10.204.62.115, 10.184.39.42 - - [02/Oct/2017:17:20:24 +0300] "GET http://www.moraal.ee/ HTTP/1.1" 200 612 "-" "Wget/1.17.1 (linux-gnu)"
10.204.62.115, 10.184.39.42 - - [02/Oct/2017:17:20:24 +0300] "GET http://www.moraal.ee/ HTTP/1.1" 200 612 "-" "Wget/1.17.1 (linux-gnu)"
10.204.62.115, 10.184.39.42 - - [02/Oct/2017:17:20:24 +0300] "GET http://www.moraal.ee/ HTTP/1.1" 200 612 "-" "Wget/1.17.1 (linux-gnu)"
...

# journalctl
-- Logs begin at Mon 2015-07-27 23:03:45 EEST, end at Tue 2015-07-28 08:41:14 EEST. --
Jul 27 23:03:45 systemd systemd-journal[171]: Runtime journal is using 4.0M (max allowed 9.3M, trying to leave 14.0M free of 89.7M available → current limit 9.3M).
Jul 27 23:03:45 systemd systemd-journal[171]: Runtime journal is using 4.0M (max allowed 9.3M, trying to leave 14.0M free of 89.7M available → current limit 9.3M).
Jul 27 23:03:45 systemd kernel: Initializing cgroup subsys cpuset
Jul 27 23:03:45 systemd kernel: Initializing cgroup subsys cpu
Jul 27 23:03:45 systemd kernel: Initializing cgroup subsys cpuacct
Jul 27 23:03:45 systemd kernel: Linux version 4.0.0-2-amd64 (debian-kernel@lists.debian.org) (gcc version 4.9.3 (Debian 4.9.3-2) ) #1 SMP Debian 4.0.8-2 (2015-07-22)
Jul 27 23:03:45 systemd kernel: Command line: BOOT_IMAGE=/vmlinuz-4.0.0-2-amd64 root=/dev/mapper/systemd-root ro console=ttyS0,9600
...

# ps aux | grep journald
..
root        172  0.1  1.0  35112  5208 ?        Ss   08:55   0:00 /lib/systemd/systemd-journald

Mar 28 03:37:01 keskus systemd-journal[29787]: Journal stopped
-- Subject: The Journal has been stopped
-- Defined-By: systemd
-- Support: http://lists.freedesktop.org/mailman/listinfo/systemd-devel

# systemctl start systemd-journald

# journalctl -xn
...
May 19 02:36:01 keskus systemd[1]: Starting Session 81008 of user root.
May 19 02:36:01 keskus systemd[1]: Started Session 81008 of user root.
May 19 02:36:01 keskus systemd[1]: Starting Journal Socket (/dev/log).
May 19 02:36:01 keskus systemd[1]: Listening on Journal Socket (/dev/log).
May 19 02:36:01 keskus systemd[1]: Starting Journal Socket.
May 19 02:36:01 keskus systemd[1]: Listening on Journal Socket.
May 19 02:36:01 keskus systemd[1]: Starting Journal Service...
May 19 02:36:01 keskus systemd[1]: Started Journal Service.
May 19 02:36:01 keskus systemd-journal[32447]: Journal started
-- Subject: The Journal has been started
-- Defined-By: systemd
-- Support: http://lists.freedesktop.org/mailman/listinfo/systemd-devel
--
-- The system journal process has been starting up, opened the journal
-- files for writing and is now ready to process requests.

# journalctl -u apache2
..
Jul 28 09:11:31 systemd systemd[1]: Starting LSB: Apache2 web server...
Jul 28 09:11:31 systemd apache2[2491]: Starting web server: apache2 failed!
Jul 28 09:11:31 systemd apache2[2491]: The apache2 configtest failed. ... (warning).
Jul 28 09:11:31 systemd apache2[2491]: Output of config test was:
Jul 28 09:11:31 systemd apache2[2491]: AH00526: Syntax error on line 1 of /etc/apache2/sites-enabled/000-default.conf:
Jul 28 09:11:31 systemd apache2[2491]: <VirtualHost> directive missing closing '>'
Jul 28 09:11:31 systemd apache2[2491]: Action 'configtest' failed.
Jul 28 09:11:31 systemd apache2[2491]: The Apache error log may have more information.
Jul 28 09:11:31 systemd systemd[1]: apache2.service: Control process exited, code=exited status=1
Jul 28 09:11:31 systemd systemd[1]: Failed to start LSB: Apache2 web server.
Jul 28 09:11:31 systemd systemd[1]: apache2.service: Unit entered failed state.
Jul 28 09:11:31 systemd systemd[1]: apache2.service: Failed with result 'exit-code'.

systemd.unit=emergency.target

..
Welcome to Debian GNU/Linux stretch/sid!

[260222.496889] systemd[1]: Set hostname to <systemd>.
[  OK  ] Created slice Root Slice.
[260223.089638] systemd[1]: Created slice Root Slice.
[260223.096748] systemd[1]: Starting Root Slice.
[  OK  ] Created slice System Slice.
[260223.109289] systemd[1]: Created slice System Slice.
[260223.115005] systemd[1]: Starting System Slice.
[  OK  ] Started Emergency Shell.
[260223.134133] systemd[1]: Started Emergency Shell.
[260223.146296] systemd[1]: Starting Emergency Shell...
         Starting Emergency Shell...
[  OK  ] Reached target Emergency Mode.
[260223.192047] systemd[1]: Reached target Emergency Mode.
[260223.205684] systemd[1]: Startup finished in 3.658s (kernel) + 967ms (userspace) = 4.626s.
[260223.221455] systemd[1]: Starting Emergency Mode.
[260223.232336] systemd[157]: emergency.service: Failed at step EXEC spawning /bin/plymouth: No such file or directory
Welcome to emergency mode! After logging in, type "journalctl -xb" to view
system logs, "systemctl reboot" to reboot, "systemctl default" or ^D to
try again to boot into default mode.
Give root password for maintenance
(or press Control-D to continue): <root parool>
root@systemd:~#

# systemctl isolate multi-user.target

# systemctl poweroff

# cat /etc/nginx/sites-available/default
..
server {
       listen 8080 default_server;
...

# cat /etc/systemd/system/proxy-to-nginx.service
[Unit]
Rquires=nginx.service
After=nginx.service
# JoinsNamespaceOf=nginx.service

[Service]
ExecStart=/lib/systemd/systemd-socket-proxyd 127.0.0.1:8080
PrivateTmp=yes
PrivateNetwork=no

# cat /etc/systemd/system/proxy-to-nginx.socket
[Socket]
ListenStream=80

[Install]
WantedBy=sockets.target

# systemctl enable proxy-to-nginx.socket
# systemctl start proxy-to-nginx.socket

# apt-get install libnss-resolve

# cat /etc/systemd/resolved.conf

[Resolve]
DNS=10.192.0.53

# systemctl start systemd-resolved
# systemctl enable systemd-resolved

# /lib/systemd/systemd-resolve-host kuutorvaja.eenet.ee
kuutorvaja.eenet.ee: 193.40.0.7

-- Information acquired via protocol DNS in 157.3ms.

# rm /etc/resolv.conf

hosts:          files resolve dns

# ln -fs /run/systemd/resolve/resolv.conf /etc/resolv.conf

# cp /lib/systemd/system/systemd-resolved.service /etc/systemd/system

[Service]

..
Environment=SYSTEMD_LOG_LEVEL=debug

# kill -SIGUSR1 PID

# systemd-resolve --status

# journalctl -f -u systemd-resolved

# localectl list-locales
C.UTF-8
en_US.utf8

# systemctl start apache2

# systemctl status apache2

# systemctl stop apache2

# systemctl disable apache2

# systemctl enable apache2

# systemctl mask apache2

# systemctl unmask apache2

# systemctl list-units --type service -a

# systemctl list-unit-files --type=service

# systemd-delta

# systemctl list-dependencies sshd.service

# systemctl show sshd.service

# systemctl edit --full nginx.service
# systemctl edit nginx.service
# systemctl cat nginx.service

# cat /etc/systemd/network/50-static.network
[Match]
Name=host0

[Network]
Address=192.168.10.16/24
Gateway=192.168.10.254

# cat /etc/network/interfaces
source /etc/network/interfaces.d/*
auto lo
iface lo inet loopback

# systemctl start systemd-networkd

..
[Network]
Gateway=192.168.10.254

[Address]
Address=192.168.10.16/24

[Address]
Address=110:1/64

# systemctl edit getty@tty1
..

[Service]
TTYVTDisallocate=no

...

# mkdir /etc/systemd/system/getty@tty1.service.d
# cat /etc/systemd/system/getty@tty1.service.d/noclear.conf
[Service]
TTYVTDisallocate=no

# reboot

# cat /etc/default/grub
..
GRUB_CMDLINE_LINUX_DEFAULT=""
...

# update-grub

# journalctl -b

# mkdir /var/log/journal
# sed -ri s/^#Storage=auto/Storage=persistent/ /etc/systemd/journald.conf

# journalctl --list-boots

# journalctl -b -2

# journalctl -n 20 -f -u ssh

# grep -v "^#" /etc/systemd/system.conf

[Manager]
DefaultCPUAccounting=yes
DefaultBlockIOAccounting=yes
DefaultMemoryAccounting=yes

# systemctl set-property nginx.service MemoryLimit=10M

$ systemd-run --user --unit=limit-test.scope --scope -p MemoryAccounting=yes -p MemoryLimit=2M bash

$ systemctl show --user limit-test.scope | grep Mem
MemoryAccounting=yes
MemoryLimit=2M

# loginctl list-sessions
   SESSION        UID USER             SEAT             TTY
        31          0 root             seat0            /dev/tty2
       189       1001 priit            seat0            /dev/tty4
         2       1000 imre             seat0
        c5        111 lightdm          seat0
       187       1001 priit            seat0            /dev/tty3
        33       1000 imre             seat0

6 sessions listed.

# ls -ld /usr/lib/tmpfiles.d/*
-rw-r--r-- 1 root root  238 Dec  2  2015 /usr/lib/tmpfiles.d/00rsyslog.conf
-rw-r--r-- 1 root root  153 Dec  2  2015 /usr/lib/tmpfiles.d/dbus.conf
-rw-r--r-- 1 root root  577 Jul  5 16:56 /usr/lib/tmpfiles.d/debian.conf
-rw-r--r-- 1 root root  362 Jul 19 02:56 /usr/lib/tmpfiles.d/home.conf
-rw-r--r-- 1 root root 1098 Jul 19 02:56 /usr/lib/tmpfiles.d/journal-nocow.conf
-rw-r--r-- 1 root root  812 Jul 19 02:56 /usr/lib/tmpfiles.d/legacy.conf
-rw-r--r-- 1 root root   61 Apr 16  2016 /usr/lib/tmpfiles.d/lvm2.conf
-rw-r--r-- 1 root root  239 Feb  5  2016 /usr/lib/tmpfiles.d/passwd.conf
-rw-r--r-- 1 root root  176 Feb 21  2016 /usr/lib/tmpfiles.d/postgresql.conf
-rw-r--r-- 1 root root   33 Jun  9  2015 /usr/lib/tmpfiles.d/screen-cleanup.conf
-rw-r--r-- 1 root root   31 Mar 16  2017 /usr/lib/tmpfiles.d/sshd.conf
-rw-r--r-- 1 root root  313 Jul  4 10:37 /usr/lib/tmpfiles.d/sudo.conf
-rw-r--r-- 1 root root 1544 Jul 19 02:56 /usr/lib/tmpfiles.d/systemd.conf
-rw-r--r-- 1 root root  496 Jul 19 02:56 /usr/lib/tmpfiles.d/systemd-nologin.conf
-rw-r--r-- 1 root root  637 Jul 19 02:56 /usr/lib/tmpfiles.d/tmp.conf
-rw-r--r-- 1 root root  532 Jul 19 02:56 /usr/lib/tmpfiles.d/var.conf
-rw-r--r-- 1 root root  623 Jul 19 02:56 /usr/lib/tmpfiles.d/x11.conf
-rw-r--r-- 1 root root   41 Aug 16 12:13 /usr/lib/tmpfiles.d/zabbix-agent.conf

# systemctl list-timers
NEXT                          LEFT     LAST                          PASSED  UNIT                         ACTIVATES
Tue 2017-07-25 06:52:49 EEST  6h left  Mon 2017-07-24 06:49:40 EEST  17h ago apt-daily.timer              apt-daily.service
Tue 2017-07-25 10:41:54 EEST  10h left Mon 2017-07-24 10:41:54 EEST  13h ago systemd-tmpfiles-clean.timer systemd-tmpfiles-clean.service

# cat /run/systemd/generator/var-lib-postgresql.mount
# Automatically generated by systemd-fstab-generator

[Unit]
SourcePath=/etc/fstab
Documentation=man:fstab(5) man:systemd-fstab-generator(8)
Before=local-fs.target
Requires=systemd-fsck@dev-system-var_lib_postgresql.service
After=systemd-fsck@dev-system-var_lib_postgresql.service

[Mount]
What=/dev/system/var_lib_postgresql
Where=/var/lib/postgresql
Type=ext4

# mount /var/lib/postgresql

Feb 20 00:57:33 ky-test kernel: [1210006.815639] EXT4-fs (dm-6): mounted filesystem with ordered data mode. Opts: discard
Feb 20 00:57:33 ky-test systemd[1]: var-lib-postgresql.mount: Unit is bound to inactive unit dev-system-var_lib_postgresql.device. Stopping, too.
Feb 20 00:57:33 ky-test systemd[1]: Unmounting /var/lib/postgresql...
Feb 20 00:57:33 ky-test systemd[1]: Unmounted /var/lib/postgresql.

# systemctl daemon-reload

systemd-modules-load.service

# ls -ld /etc/modules-load.d/modules.conf
lrwxrwxrwx 1 root root 10 Oct  9 14:58 /etc/modules-load.d/modules.conf -> ../modules

# ps aux | grep '/lib/systemd/systemd-'
root       173  0.0  0.5  28188  2912 ?        Ss   15:39   0:00 /lib/systemd/systemd-journald
root       190  0.0  0.7  44072  4000 ?        Ss   15:39   0:00 /lib/systemd/systemd-udevd
systemd+   388  0.0  0.4  97952  2312 ?        Ssl  15:39   0:00 /lib/systemd/systemd-timesyncd
root       396  0.0  0.5  28352  2772 ?        Ss   15:39   0:00 /lib/systemd/systemd-logind
systemd+   402  0.0  0.5  28504  2892 ?        Ss   15:39   0:00 /lib/systemd/systemd-networkd
systemd+  1004  0.0  0.5  31340  2880 ?        Ss   16:00   0:00 /lib/systemd/systemd-resolved

# systemctl daemon-reload

# systemctl daemon-reexec

# machinectl shell imre@

$ env | grep XDG
XDG_SESSION_TYPE=tty
XDG_SESSION_CLASS=user
XDG_SESSION_ID=29
XDG_RUNTIME_DIR=/run/user/1000
XDG_DATA_DIRS=/usr/local/share:/usr/share:/var/lib/snapd/deskto

Systemd kasutamine

Sissejuhatus

Tööpõhimõte

Paigaldamine

Kasutamine

systemd-timedated

Rakenduste kasutamine systemd keskkonnas

PostgreSQL kasutamine

Samba

OpenVPN

Serial konsool

NUT

iptables

rsyslog

Varnish

Logimine

Süsteemi alglaadimine

Märkused

Apache veebiserver

Kasulikud lisamaterjalid

targetite vahel liikumine

systemd-socket-proxyd

systemd-resolved

localectl

Service haldamine

systemd-networkd

Konsooli alglaadimisjärgse puhastamise lõpetamine

journalctl kasuamine

Systemd debugimine

Ressursikasutuse kontrollimine

systemd-run

systemd-boot

systemd-logind

systemd user services

tmpfiles-setup

Timer

systemd-fstab-generator

Märkused

su ja sudo kasutamine

Kasulikud lisamaterjalid

Navigeerimismenüü

Otsing
